STAGEPAS 100 Portable PA System
EXPAND YOUR RANGE. EXTEND YOUR REACH.
The STAGEPAS 100 portable PA system strikes a perfect balance between high-quality sound and ultimate portability, allowing you to turn virtually any location into your own intimate live stage. Available in two versions, one with a battery and one without, the lightweight yet durable design, easy operation, and impressive sound of the STAGEPAS 100 will help you connect with your audience and fully express your performance.
The battery-equipped STAGEPAS 100BTR mkII also provides audio I/O via USB or Bluetooth®, letting you deliver crystal-clear sound to remote audiences or communicate seamlessly with colleagues anywhere.
Compact design. Big sound.
Far more than just a speaker, the STAGEPAS 100 delivers impressive sonic performance by leveraging some of the same technologies used in our high-end professional products. A powerful, high-quality coaxial compression driver combined with proprietary FIR-X filters for the HF and LF crossover deliver sound pressure, precise phase response, and a natural dispersion to ensure every nuance of your performance is conveyed loud and clear to your audience.
Advanced technology condensed into a compact unit
Coaxial compression drivers utilize a common motor structure sharing a single magnet, reducing weight and bringing LF and HF closer together to provide a more ideal point sound source. Since sharing a magnet reduces magnetic flux, lowering the sound pressure, these drivers use voice coils made of a light aluminum material called "CCAW" wound in a square shape referred to as "Edgewound" to increase magnetic flux and ensure sufficient sound pressure, and also feature a device called a "demodulation ring" that suppresses magnetic flux disturbance to maintain a high level of sound quality. Additionally, they are equipped with an air venting structure in the basket to reduce LF wavering at high volumes, a polyimide diaphragm to balance HF durability with smooth high-frequency characteristics, and a short aluminum horn for better directional control, durability, and heat dissipation. These compact units house advanced, state-of-the-art technologies.
Start the show in seconds
With effortless setup and intuitive operation, the STAGEPAS 100 will have you sounding great in no time. Power on, plug in your mic and instrument, raise the volume, and you’re ready. The master EQ is right on the front panel, making it easy to dial in your sound or adjust settings on the fly.
A PA in the palm of your hand
With all the essentials for a compact PA packed into a durable cabinet weighing just 11 pounds, the STAGEPAS 100 takes portability to a whole new level. It's like having a personal stage you can easily carry in one hand and set up anywhere, anytime.
Support hybrid application
The battery-equipped STAGEPAS 100BTR mkII offers audio I/O functionality via a USB or Bluetooth connection, allowing voice signals to be sent and received to and from a computer or smartphone. It can also be used for hybrid applications such as streaming of live performances or online seminars via mobile devices connected to a network.
Six hours of nonstop performance
The STAGEPAS 100BTR mkII and STAGEPAS 100BTR are compatible with large-capacity lithium-ion batteries capable of up to 6 hours of continuous operation, delivering reliable performance in environments where there is no power source available.
*STAGEPAS 100BTR mkII supports USB PD (Power Delivery).
Multipoint Bluetooth® connectivity
The STAGEPAS 100 comes equipped with Bluetooth® for wireless connection with your smartphones and tablets for music/audio playback.
The right direction
Easily control your coverage area with the carrying handle that doubles as a stand when the unit is placed on the floor. The attachment screws can be adjusted to change the angle so you can direct your sound exactly where it needs to go.
Mounting possibilities
The handle of the STAGEPAS 100 also features a 3/8" diameter screw hole that mounts upon a microphone stand for more sound dispersion options.
Whenever. Wherever.
The dedicated BAG-STP100 carrying bag features internal pockets for storing adapters, cables etc., as well as a padded shoulder strap for safe and easy transport to any location.
Compatible Hy-brid applications
The STAGEPAS 100BTR mkII is capable of sending and receiving audio signals to and from a computer or smartphone via USB or Bluetooth®.
Product Information
STAGEPAS 100BTR mkII Portable PA System
Portable PA system equipped with a 100 W power amp, coaxial compression driver with 1.4” voice coil HF and 6.5” cone LF, a 3-channel mixer, internal lithium-ion battery, audio I/O functionality via USB or Bluetooth®, and USB Power Delivery (USB PD) supported.
- 100 W Class-D amplifier
- 1.4” HF + 6.5” LF high-quality coaxial compression driver using an FIR filter for the crossover
- 3-channel mixer (2 monaural mic/line + 1 line)
- Equipped with a 2-band master EQ
- Compatible with Hi-Z input (Channel 2 only)
- Equipped with mix-out
- Carrying handle doubles as an adjustable stand
- Compatible with audio accompaniment over Bluetooth
- Optional carrying bag (BAG-STP100) available for convenient transport
- Internal lithium-ion battery
- Equipped with audio I/O functionality via USB or Bluetooth® connection
- USB Power Delivery (USB PD) supported
STAGEPAS 100BTR Portable PA System
Portable PA system equipped with a 100 W power amp, coaxial compression driver with 1.4” voice coil HF and 6.5” cone LF, a 3-channel mixer, and internal lithium-ion battery.
- 100 W Class-D amplifier
- 1.4” HF + 6.5” LF high-quality coaxial compression driver using an FIR filter for the crossover
- 3-channel mixer (2 monaural mic/line + 1 line)
- Equipped with a 2-band master EQ
- Compatible with Hi-Z input (Channel 2 only)
- Equipped with mix-out
- Carrying handle doubles as an adjustable stand
- Compatible with audio accompaniment over Bluetooth
- Optional carrying bag (BAG-STP100) available for convenient transport
- Internal lithium-ion battery
STAGEPAS 100 Portable PA System
Portable PA system equipped with a 100 W power amp, coaxial compression driver with 1.4” voice coil HF and 6.5” cone LF, and a 3-channel mixer.
- 100 W Class-D amplifier
- 1.4” HF + 6.5” LF high-quality coaxial compression driver using an FIR filter for the crossover
- 3-channel mixer (2 monaural mic/line + 1 line)
- Equipped with a 2-band master EQ
- Compatible with Hi-Z input (Channel 2 only)
- Equipped with mix-out
- Carrying handle doubles as an adjustable stand
- Compatible with audio accompaniment over Bluetooth
- Optional carrying bag (BAG-STP100) available for convenient transport
Options
The colors and finishes shown may vary from those on the actual products.
