SX Series

A more intimate concert grand.


We took everything we learned from our Flagship CF concert grand and crafted an instrument that’s perfectly suited for the conservatory, recital hall or intimate stage. SX pianos are almost entirely handcrafted and feature our patented Acoustic Resonance Enhancement process to precisely control the aging of wood in the rims for a warm, elegant tone. A completely redesigned hammer helps produce a wide palette of colors with an intimate sound and depth rarely found in a concert grand.


  • Wood soundboard.
    SX Series soundboards share the same DNA as our world-renowned flagship CFX. The soundboards and ribs are crafted from hand selected European Spruce to deliver warm overtones and a wide range of colors.
  • View of the inside of a piano.
    A patented wood maturation process we call A.R.E. (Acoustic Resonance Enhancement) allows our craftsmen to precisely control the moisture content in the hand-selected wooden rims of every SX Series piano. The result is a warm, intimate tone with the sustained resonance comparable to a vintage instrument.
  • Image showing a piano design drawing on a pad with a pen.
    The back posts have been thickened to give SX Series pianos a robust backbone to project the most powerful fortissimo while maintaining its rich, resonant sound. A time-honored assembly process decreases the use of glue on the inner and outer rims so nothing gets in the way of the natural vibrations of the wood.
  • Individual piano hammers which are small pieces of wood with one end wrapped in felt with a handful of felt in the background.
    Yamaha craftsmen spent years shaping the finest materials into a hammer that helps create warm, powerful tones with a full range of beautiful, subtle colors.
  • Someone wearing knit workgloves handwrapping a piano string that has been stretched taut.
    Our artisans painstakingly wind pure copper by hand to adjust the balance and tension of every bass string in this superb instrument. You can hear the attention to detail in every note.
  • Someone adjusting the hammers with a small pair of pliers.
    Each SX Series piano is meticulously voiced, regulated and tuned in our Concert Piano Workshop to bring out the nuanced colors, harmonics and resonance from these superb instruments.
  • Showing inside of piano where frame meets board.
    Yamaha was the first company to use an advanced Vacuum Shield Mold casting technology called V-Pro to create a stronger, lighter, more durable frame worthy of the grandest grand piano. Every SX Series frame is built to our exacting specifications at our Iwata Forge in Japan.
  • A bare wood frame curved as the piano rim.
    The SX Series is made for the stage, with graceful curves that are as elegant and expressive as its unmistakable tone.
  • S7X

    Crafted by Yamaha in Kakegawa, Japan
    Soundboard: European Spruce
    Soundboard Ribs: European Spruce
    Back Posts: 3 - Spruce
    Bridge Construction: Two-piece separated
    Frame: V-Pro Vacuum Shield Mold Process
    Tone Collector: Yes
    Key Material: Seasoned spruce
    White Key surfaces: Ivorite™
    Black Key surfaces: Wood composite
    Fallboard: Soft-close
    Lid lock: Yes
    Pedal: Shift/Sostenuto/Damper
    Caster: Heavy duty double-wheeled solid brass casters with locks
    Weight: 904 lbs (410 kg)
    More info

    Colors / Finishes Polished Ebony

  • S6X

    Crafted by Yamaha in Kakegawa, Japan
    Soundboard: European Spruce
    Soundboard Ribs: European Spruce
    Back Posts: 3 - Spruce
    Bridge Construction: Two-piece separated
    Frame: V-Pro Vacuum Shield Mold Process
    Tone Collector: Yes
    Key Material: Seasoned spruce
    White Key surfaces: Ivorite™
    Black Key surfaces: Wood composite
    Fallboard: Soft-close
    Lid lock: Yes
    Pedal: Shift/Sostenuto/Damper
    Caster: Heavy duty double-wheeled solid brass casters with locks
    Weight: 859 lbs (390 kg)
    More info

    Colors / Finishes Polished Ebony

  • S5X

    Crafted by Yamaha in Kakegawa, Japan
    Soundboard: European Spruce
    Soundboard Ribs: European Spruce
    Back Posts: 3 - Spruce
    Bridge Construction: Two-piece separated
    Frame: V-Pro Vacuum Shield Mold Process
    Tone Collector: Yes
    Key Material: Seasoned spruce
    White Key surfaces: Ivorite™
    Black Key surfaces: Wood composite
    Fallboard: Soft-close
    Lid lock: Yes
    Pedal: Shift/Sostenuto/Damper
    Caster: Heavy duty double-wheeled solid brass casters with locks
    Weight: 772 lbs (350 kg)
    More info

    Colors / Finishes Polished Ebony

  • S3X

    Built by Yamaha in Kakegawa, Japan
    Soundboard: European Spruce
    Soundboard Ribs: Spruce
    Back Posts: 3 - Spruce
    Bridge Construction: Two-piece separated
    Frame: V-Pro Vacuum Shield Mold Process
    Tone Collector: Yes
    Key Material: Seasoned spruce
    White Key surfaces: Ivorite™
    Black Key surfaces: Wood composite
    Fallboard: Soft-close
    Lid lock: Yes
    Pedal: Shift/Sostenuto/Damper
    Caster: Heavy duty double-wheeled solid brass casters with locks
    Weight: 728 lbs (330 kg)
    More info

    Colors / Finishes Polished Ebony
